Fiat Ducato - Rear Ceiling Light

F0N0091m
fig. 195
F0N0090m
fig. 194
F0N0093m
fig. 197
F0N0092m
fig. 196
❒ change the bulb F-fig. 197 by releasing it from
the side contacts and making sure the new bulb is
correctly fastened between the contacts;
❒ re-close the protection lid E-fig. 197 and secure ceiling
light D-fig. 196 into its housing locking it properly.
REAR CEILING LIGHT
Proceed as follows to replace the bulbs:
❒ work in the points shown by the arrows and remove
the ceiling light D-fig. 196;
❒ open the protection lid E-fig. 197;
