READING RIM CODE fig. 230
Example: 6J × 15 ET43
6 = rim width in inches 1.
J = rim drop centre outline (side projection where the tyre bead rests)
2.
15 = rim nominal diameter in inches (corresponds to diameter of the tyre to be mounted)
3 = Ø.
ET43 = wheel camber (distance between the disc/rim support plane and the wheel rim centre line).
230
DASHBOARD
AND CONTROLS
SAFETY
STARTING
AND DRIVING
WARNING LIGHTS
AND MESSAGES
IN AN EMERGENCY
MAINTENANCE
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
215/70 R15C 109/107S
225/70 R15C 112/110S
215/70 R15CP 109/107Q
215/75 R16C 116/114R
225/75 R16C 118/116R
225/75 R16CP 116/114Q
6J × 15" - H2
6J × 15" - H2
6J × 16" - H2
6J × 16" - H2
Versions Rims Tyres provided
Ducato (except recreational)
Ducato (recreational)
Ducato Maxi (except recreational)
Ducato Maxi (recreational)
If using M+S winter tyres with speed index lower than “S” for 15 inch wheels and “R” for 16 inch wheels, respect the max vehicle
speed indicated in the table: Maximum speed index.
IMPORTANT Use only the tyres shown in the vehicle vehicle registration document.
If using class C tyres on a Camping vehicle, always use wheels with a metal inflation valve. When replacing, it is always advisable to
use Camping tyres.
223-276 DUCATO LUM EN 12-02-2010 13:09 Pagina 230
