PASSENGER COMPARTMENT HEATING
Proceed as follows:
❒ turn the knob A to the red section;
❒ turn the knob C to the required position;
❒ turn the knob B to the required speed.
RAPID PASSENGER COMPARTMENT
HEATING
For the rapid heating of the passenger compartment, pro-
ceed as follows:
❒ turn the knob A to the red section;
❒ switch on the air recirculation by turning the knob D
to
Ò
;
❒ turn the ring nut C to
©
;
❒ turn the knob B to 4 - (max. fan speed).
Then use the controls to maintain the required comfort
conditions and turn the knob D to
⁄
to turn the air re-
circulation off and to prevent misting up.
IMPORTANT With cold engine, you have to wait for a few
minutes to let the system fluid reach the operating tem-
perature.
Air distribution rotating wheel C
∂
to direct air to the centre and side vents;
ß
to send air to the feet and direct cooler air to the dash-
board vents, in intermediate temperature conditions;
©
for heating when the outside temperature is very low:
to direct as much air as possible to the feet;
®
to warm the feet and, at the same time, demist the wind-
screen;
- for quick windscreen demisting.
Air recirculation on/off knob D
When the knob D is turned to
Ò
the internal air re-
circulation is activated.
When the knob D is turned to
Ú
the internal air re-
circulation is deactivated.
PASSENGER COMPARTMENT VENTILATION
To ventilate the passenger compartment properly, pro-
ceed as follows:
❒ turn the ring nutA to the blue section;
❒ switch off the air recirculation by turning the knob D to
Ú
;
❒ turn the ring nut C to
∂
;
❒ turn the knob B to the required speed.
