The presence of water in the feeding cir-
cuit may cause severe damage to the in-
jection system and irregular engine oper-
ation. If warning light
c lights up (on some versions
with the message on the display), contact a Fiat
Dealership as soon as possible to have the system
bled. If the above indications come on immediate-
ly after refuelling, water has probably been poured
into the tank: turn the engine off immediately and
contact Fiat Dealership.
WATER IN DIESEL FUEL FILTER
(Multijet versions – amber)
When the key is turned to the MAR position the warn-
ing light comes on but should go out after a few seconds.
The warning light turns on when there is water in the
diesel fuel filter.
On some versions the display shows the dedicated message.
c
VEHICLE PROTECTION SYSTEM
FAILURE – FIAT CODE (amber)
Turning the key to MAR the warning light shall flash only
once and then go off.
If with the ignition key on MAR, the warning light stays on,
this indicates:
Y
EXTERNAL LIGHT FAILURE
(amber)
The warning light will come on (some versions only) when
a fault to one of the following lights is detected:
– side lights
– brake lights
– rear fog lights
– direction indicators.
The failure referring to these lights could be: one or more
blown bulbs, a blown protection fuse or an electric con-
nection cut-off.
On some versions the display shows the dedicated message.
W
❒ a possible failure (see “Fiat Code system” in section
“Dashboard and controls”);
❒ a possible theft attempt with an alarm; in this case the
warning light goes off after approximately 10 seconds.
If with the engine running the warning light
Y
flashes, the
vehicle is not protected by the engine inhibitor device (see
“Fiat Code system” in section “Dashboard and controls”).
Contact Fiat Dealership to have all the key stored.
