Air distribution rotating wheel C
∂
to direct air to the centre and side vents;
ß
to send air to the feet and direct cooler air to the dash-
board vents, in intermediate temperature conditions;
©
for heating when the outside temperature is very low:
to direct as much air as possible to the feet;
®
to warm the feet and, at the same time, demist the
windscreen;
-
for quick windscreen demisting.
Air recirculation on/off knob D
Press the button (button LED on) to turn the air internal
recirculation on.
Press the button again (button LED off) to turn the air
internal recirculation off.
Button E turns climate control system on/off
Press the button (button LED on) to turn the climate con-
trol system on.
Press the button again (button LED off) to turn the climate
control system off.
PASSENGER COMPARTMENT VENTILATION
To ventilate the passenger compartment properly, proceed
as follows:
❒
turn the ring nut A to the blue section;
❒
switch off the air recirculation by turning the knob D to
Ú
;
❒
turn the ring nut C to
∂
;
❒
turn the knob B to the required speed.
CLIMATE CONTROL (cooling)
For fast cooling of the passenger compartment, proceed
as follows:
❒
turn the ring nut A to the blue section;
❒
switch on the air recirculation by turning the knob D
to
Ò
;
❒
turn the ring nut C to
∂
;
❒
press the button E to turn the climate control system
on; the LED in the button E will come on;
❒
turn the knob B to 4
-
(max. fan speed).
