F0N0188m
fig. 118
F0N0062m
fig. 119
ELECTRIC WINDOW
MECHANISM fig. 119
Switches on the inner armrest of the driver’s door con-
trol the following with the ignition key in the MAR posi-
tion:
A to open/close the left front window;
B right front window opening/closing.
Continuous automatic operation
All versions are equipped with automatic raising and low-
ering of the front, driver’s side window.
Keep one of the buttons pressed for longer than half a sec-
ond to operate the automatic continuous window oper-
ation function . The window stops when it reaches the end
of travel position or when the button is pressed again.
The opening angle of the two doors may be increased for
more convenient loading and unloading. To carry out
this operation, press the button A-fig. 118; this allows
the doors to be opened to about 180 degrees.
103
DASHBOARD
AND CONTROLS
SAFETY
STARTING
AND DRIVING
WARNING LIGHTS
AND MESSAGES
IN AN EMERGENCY
MAINTENANCE
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
This spring loaded system has activation
forces that were designed for optimum
comfort. Accidental knocks or a strong gust of
wind may release the springs and let the doors
close spontaneously.
WARNING
With the doors opened to 180 degrees, no
locking system is effective. Do not use this
opening with the vehicle parked on a gradient or
when it is windy.
WARNING
037-122 DUCATO LUM EN 11-02-2010 14:27 Pagina 103
