F0N0147m
fig. 24
F0N0139m
fig. 25
AIR SEAT
The seat is equipped with a mechanical spring system and
hydraulic shock absorber to ensure maximum comfort and
safety. The system of springs also effectively absorbs im-
pact from uneven road surfaces.
See the description in the “Front seats” section for the
lengthwise adjustments, height adjustments, backrest ad-
justment, lumbar adjustment and armrest adjustment.
Damper weight adjustment
Use the adjustment knob A – fig. 25 to set the required
setting based on body weight, with settings between 40 kg
and 130 kg.
To lower the seat: whilst sitting, move the lever B upwards
(front part of the seat) or the lever C (rear part of the
seat) and place your body weight on the part of the seat
to be lowered.
Backrest angle adjustment fig. 23
Turn knob D.
38
DASHBOARD
AND CONTROLS
SAFETY
STARTING
AND DRIVING
WARNING LIGHTS
AND MESSAGES
IN AN EMERGENCY
MAINTENANCE
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
For maximum protection, keep the back
of your seat upright, lean back into it and
make sure the seat belt fits closely across your
chest and hips.
WARNING
Lumbar adjustment
To adjust, turn knob E – fig. 24.
037-122 DUCATO LUM EN 11-02-2010 14:26 Pagina 38
