F0N0030m
fig. 62
F0N0032m
fig. 64
F0N0031m
fig. 63
MAIN BEAM HEADLIGHTS fig. 65
When the control is in position 2 pull the lever towards
the steering wheel (2nd rocking position).
The warning light 1 in the instrument panel will come on.
To turn the main beam headlights off, pull the lever again
towards the steering wheel (the dipped beams will turn
on again).
EXTERIOR LIGHTS
The left lever includes the controls for the exterior lights.
The exterior lights can only be switched on when the
ignition key is in the ON position.
LIGHTS OFF fig. 62
Control turned to position
O.
SIDE LIGHTS fig. 63
Turn the control to position 6.
The warning light 3 in the instrument panel comes on.
DIPPED HEADLIGHTS fig. 64
Turn the control to position 2.
The warning light 3 in the instrument panel comes on.
72
DASHBOARD
AND CONTROLS
SAFETY
STARTING
AND DRIVING
WARNING LIGHTS
AND MESSAGES
IN AN EMERGENCY
MAINTENANCE
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
037-122 DUCATO LUM EN 11-02-2010 14:26 Pagina 72
