F0N0828m
fig. 170
❒
if at least 3 bar pressure is read, restore the correct
pressure specified in the paragraph “Inflation pressure”
in the “Technical Specifications” section (with engine
running and handbrake on) and restart;
❒
drive with the utmost care to the nearest Fiat Dealer-
ship.
176
DASHBOARD
AND CONTROLS
SAFETY
STARTING
AND DRIVING
WARNING LIGHTS
AND MESSAGES
IN AN EMERGENCY
MAINTENANCE
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
Remember to inform the workshop that
the tyre has been treated with a quick re-
pair kit. Hand the leaflet over to the staff who will
be dealing with the the tyre treated using the tyre
repair kit.
WARNING
If different tyres from the ones supplied
with the vehicle are used, the repair can-
not be carried out. If the tyres are replaced, it is
advisable to use those approved by the manufac-
turer. contact a Fiat Dealership .
WARNING
❒
Undo the cap for the tyre valve, extract the black pipe
C-fig. 170 and tighten the ring nut on the tyre valve.
❒
Insert the pin in the nearest 12 V current socket and
start the engine.
❒
Rotate the selector clockwise to the pressure renew-
al position.
❒
Activate the kit by pressing the on/off switch. Inflate the
tyre to the pressure specified in the “Inflation pressure”
paragraph, in the “Technical Specifications” section.
NOTE If the tyre has to be deflated, press the dedicated
button B illustrated in fig. 171.
For a more accurate reading, it is advisable to check the
pressure reading on the pressure gauge with the com-
pressor off and without moving the centre selector from
the repair position.
FOR CHECKING AND RESTORING
PRESSURE ONLY
The compressor may also be used for restoring pressure
only.
❒
Engage the handbrake.
165-198 DUCATO LUM EN 12-02-2010 8:43 Pagina 176
