F0N0058m
fig. 99
F0N0191m
fig. 101
F0N0190m
fig. 100
FLAP ON BENCH
(for versions/markets where provided)
To use, pull tab A-fig. 102 and lower the flap.
The flap is equipped with two cup holders and a support
surface with a paper holder clip.
SHELF ABOVE THE CAB fig. 100
(for versions/markets where provided)
This is located above the driver’s cab and is designed to
store light objects.
Maximum permitted load:
– localised .........................................................................10 kg
– distributed over the entire surface of the shelf ....20 kg
CAB GLOVE COMPARTMENT fig. 101
(for versions/markets where provided)
The storage compartment is fitted above the sun visor and
is designed for the easy storage of light objects (e.g. doc-
uments, road maps etc.).
92
DASHBOARD
AND CONTROLS
SAFETY
STARTING
AND DRIVING
WARNING LIGHTS
AND MESSAGES
IN AN EMERGENCY
MAINTENANCE
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
037-122 DUCATO LUM EN 11-02-2010 14:26 Pagina 92
