Fiat Ducato - Flap on Bench; Seat Heating

41
DASHBOARD
AND CONTROLS
SAFETY
STARTING
AND DRIVING
WARNING LIGHTS
AND MESSAGES
IN AN EMERGENCY
MAINTENANCE
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
F0N0175m
fig. 30a
F0N0149m
fig. 30c
F0N0213m
fig. 30b
FLAP ON BENCH fig. 30c
(for versions/markets where provided)
The seat is equipped with a fold-down flap that can be used
as a document support surface. To use, the pull tab A and
lower the flap. The flap is equipped with two cup holders
and a support surface with a paper holder clip.
Use the lever D – fig. 30a (on the right side of the seat)
to turn the seat.
Before turning, move the seat forward and only then ad-
just the reach fig. 27a.
Ensure the seat is locked in the driving
position before starting up the vehicle.
WARNING
Seat heating fig. 30b
(for versions/markets where provided)
With the key turned to MAR, press the button E to switch
the function on/off.
037-122 DUCATO LUM EN 11-02-2010 14:26 Pagina 41
