F0N0170m
fig. 181
F0N0339m
fig. 182
FOG LIGHTS (where provided)
To replace the front fog light bulbs A-fig. 182 proceed
as follows:
❒
steer fully to the left;
❒
open the flap on the front wheel compartment guard,
unscrewing the self-tapping screw;
❒
remove the bayonet cap;
❒
disconnect the connector;
❒
release the bulb holding clip;
❒
remove the bulb and replace it;
❒
fit the new bulb, ensuring that the outline of the metal
part coincides with the grooves on the curve of the
headlight. Then reconnect the bulb holder clip and reat-
tach electrical connector;
❒
refit the bayonet cap.
183
DASHBOARD
AND CONTROLS
SAFETY
STARTING
AND DRIVING
WARNING LIGHTS
AND MESSAGES
IN AN EMERGENCY
MAINTENANCE
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
F0N0086m
fig. 183
