Franke Flair Service Manual

TD-100343.doc
37
Fit guide, making sure the piston
positioning peg is not tilted
Drainage valve
Fit drainage valve into guide and press into
place
Fitting the left + right covers
Place cover parallel with housing and snap
spring-loaded catch into place
Fitting the pipe bend and cap
Position longitudinal guide in slot
Press retaining pegs towards hole centre
and snap into place
Place cap on upper side (cylinder) and
snap spring loaded catch into place
Functional test
Simulate the movement sequence of a
brewing process manually by turning the
nut
• CAUTION! No force should be necessary to
carry out this process!

Franke Flair Specifications

General

Type	Espresso Machine
Pump Pressure	15 bar
Product Type	Coffee Maker
Brand	Franke
Model	Flair
Voltage	220-240 V
Frequency	50-60 Hz
Material	Stainless Steel
Programmable	Yes
Auto Shut-off	Yes
Filter Type	Metal Filter
Coffee Output	Single or Double Espresso
