10.5 Outline and Installation Drawings
Figure 10-2 GMC 305 Outline Drawing
.46 11.6 TYP.
.86 21.8
84.03.31
1.27 32.2
5.34
135.6
1.24
1.69
31.4
13.0.51
.34 8.6
42.9
.080
2.03 TYP.
1.85
47.0
6.25 158.8
2. 1.
DIMENSIONS ARE NOMINAL AND TOLERANCES ARE NOT IMPLIED UNLESS SPECIFICALLY STATED. DIMENSIONS: INCHES[mm]. METRIC VALUES ARE FOR REFERENCE ONLY.
NOTES:
FRONT SURFACE OF
AIRCRAFT PANEL
