5.2 Equipment Available
5.2.1 Required Equipment
• GAP 26 Pitot/AOA Probe (010-01074-00, 010-01074-10, or 010-01074-20)
• Electrical and pneumatic connectors per installer preference. For heated probe installations where
the installer desires to shorten the provided aluminum tubing, a minimum of 8 inches of aluminum
tubing should remain between the probe and any transition to non-metallic tubing to protect the
non-metallic tubing from excessive heat.
• Mount: Standard AN5812 pitot tube mount.
• #6-32 screws (4 pcs), required length (.218” min - .312” max), recommend screws with nylon
patch on threads for thread locking for mounting probe.
• #4 or #6 (4 pcs) pan or hex head screws for mounting heater control box.
5.2.2 Additional Equipment
The connector kit in Table 5-2 can be used to install the unit, it is not provided with the GAP 26 unit.
5.3 General Specifications
See Section 2.2 for power/current specifications, and Section 2.4.1 for dimension/weight specifications.
Table 5-1 GAP 26 Part Numbers
Model
Assembly Part
Number
Unit Only Part
Number
Heater Control Box
Part Number
GAP 26 Adjustable
Mount
010-01380-00 011-03609-00 N/A
GAP 26 Probe Only 010-01074-00 011-02964-00 N/A
GAP 26 Probe Only,
Heated
010-01074-10 011-02964-10 N/A
GAP 26 Probe Only,
Heated, Regulated
010-01074-20 011-02964-20 011-02965-00
Table 5-2 Contents of GAP 26 Adjustable Mounting Kit (011-03609-00)
Item Garmin P/N Quantity
GAP 26 Adjustable Mount, Washer Plate 115-02075-00 1
GAP 26 Adjustable Mount, Tube Bracket 117-00659-00 1
GAP 26 AN5812 Mount Tube, Aluminum 117-02013-00 1
