190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 23-64
23.16.5 MIC Audio
PILOT MIC IN and COPILOT MIC IN are standard carbon or dynamic MIC inputs with integrated
preamps providing minimum 20 mVrms into a 150 Ω AC load.
PILOT MIC IN and COPILOT MIC IN are set in the factory so that 150 mVrms modulates the transmitter
to 90% nominally at 1000 Hz. The microphone gain adjustment is made through Configuration Mode.
23.16.6 Aux Mono Audio
Auxiliary audio mono audio inputs have a nominal input impedance of 600 Ω, max. rated input level is
5 Vrms.
23.16.7 Headset Audio
Headset audio outputs
Pin Name Pin I/O
PILOT MIC IN 17 In
PILOT MIC LO 36 --
COPILOT MIC IN 16 In
COPILOT MIC LO 34 --
Pin Name Pin I/O
AUX MONO IN 1 32 In
AUX 1 LO 31 --
AUX MONO IN 2 9 In
AUX 2 LO 28 --
Pin Name Pin I/O
PILOT HS RIGHT 13 Out
PILOT HS LEFT 14 Out
PILOT HS LO 33 --
COPILOT HS RIGHT 11 Out
COPILOT HS LEFT 12 Out
COPILOT HS LO 30 --
