17.5 Outline and Installation Drawings
Figure 17-4 GSU 25 Outline Drawing
.9 24
1.0
25
2.1 53
NOTES:
DIMENSIONS: INCHES [mm]. METRIC VALUES ARE FOR REFERENCE ONLY.1.
DIMENSIONS ARE NOMINAL AND TOLERANCES ARE NOT IMPLIED UNLESS SPECIFICALLY STATED.2.
CENTER OF GRAVITY LOCATION INCLUDES UNIT WITH CONNECTOR KITS.3.
THE GSU25 MOUNTING HOLES HAVE AN OFFSET SPACING PATTERN. THE DIFFERENCE PREVENTS THE 4.
UNIT FROM BEING RE-INSTALLED IN THE WRONG ORIENTATION.
101.5
4.00
2.61
66.2
1.52
38.6
2.50 63.4
1.72 43.7
3.400
86.36
2.000
6.32
.249
.299
.209
7.59
5.32
SEE NOTE 4
50.80
4x
88.903.500
.249
6.32
To Next Page
