1.3 Optional Garmin Equipment
1.3.1 Garmin Optional LRU Installation Kits
Table 1-3 Available GDU Display Units
Item Part Number
G3X - GDU 370, 7" Portrait Non-Touch Display** 010-00667-15
G3X Touch™ Avionics - GDU 460, 10.6" Display 010-01057-00
G3X Touch - GDU 465, 10.6" Display with SXM Receiver 010-01057-10
G3X Touch - GDU 470, 7" Portrait Display 010-01765-00
G3X Touch - GDU 450, 7" Landscape Display 010-01056-00
G3X Touch - GDU 455, 7” Landscape Display with SXM Receiver 010-01056-10
*Any combination of G3X Touch displays can be installed in a single system (maximum of six displays)
**Not compatible with G3X Touch displays
Table 1-4 LRU Connector/Installation Kits
LRU
Connector/Installation
Kit Part Number
Installation Kit
Included with LRU?
GAD 27 Flaps/Lights/Trim
Controller
011-03877-00 (Table 3-2) N
GAD 29 ARINC 429 Adapter 011-03271-00 (Table 4-2) N
GAP 26 Air Data Probe 011-03609-00 (Table 5-2) N
GDU 37X Display 011-01921-00 (Table E-1) Y
GDU 45X Display 010-12150-01 (Table 6-1) N
GDU 46X Display 010-12150-00 (Table 6-2) N
GDU 470 Display 010-12150-02 (Table 6-3) N
GDL® 39R data transceiver
(9 Pin Connector)
010-11825-20 (Table 1-6) N
GDL 5XR Data Link 010-12498-60 (Table 1-6) N
GEA™ 24 Engine Interface Module 011-02886-00 (Table 7-2) N
GHA 15 Height Advisor
011-05278-00, Conn Kit (Table 8-3)
011-06097-00, Install Kit (Table 8-4)
N
GMC 305 Mode Controller 010-12034-00 (Table 10-2) N
GMC 307 Mode Controller 010-12421-00 (Table 11-2) N
GMC 507 Mode Controller 010-01946-00 (Table 12-2) N
GMU 11 Magnetometer 011-04349-90, Install Kit (Table 13-3) N
GMU 22 Magnetometer 011-00871-10, Conn Kit (Table 14-3) N
GPS 20A 011-03914-00 (Table 15-3) N
