190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 21-7
21.2 Engine Sensor Applications
21.2.1 Lycoming/Continental Engine Applications
Table 21-2 and Table 21-3 list Garmin sensor kits available for G3X installations with 4-cylinder and
6-cylinder Lycoming and Continental piston engines. Refer to Sensor Interface drawings in Section 27
for
sensor wiring guidance.
For 8-cylinder Lycoming engine applications, refer to Section 21.2.5
.
For retrofit applications, where a G3X system is installed in a completed aircraft with a Lycoming/
Continental engine, refer to Section 21.2.6
.
21.2.1.1 Lycoming/Continental RPM
Engine speed for Lycoming and Continental engines may be sensed by an RPM sensor mounted on the
mechanical tach drive, a sensor mounted on the magneto, or through the digital tach signal output from an
electronic ignition system. Refer to Section 21.3.5
.
Table 21-2 Contents of G3X Sensor Kit, 4 Cylinder Lycoming/Continental (K00-00512-10)
Item Garmin P/N Quantity
Garmin GPT 150G 011-05783-30 1
Fuel Flow Transducer, EI FT-60 494-10001-00 1
Absolute Pressure Transducer, Kavlico 30 PSI 011-05783-00 1
Type K Thermocouple, 3/8-24 Threaded, CHT, Alcor 86253 494-70000-00 4
Type K Thermocouple, Clamp, EGT, Alcor 86255 494-70001-00 4
RTD, Oil Temperature, UMA 1B3-2.5R 494-70004-00 1
Shunt, Ammeter, +/-50 mV, 100 amps, UMA 1C4 909-D0000-00 1
Table 21-3 Contents of G3X Sensor Kit, 6 Cylinder Lycoming/Continental (K00-00513-10)
Item Garmin P/N Quantity
Garmin GPT 150G 011-05783-30 1
Fuel Flow Transducer, EI FT-60 494-10001-00 1
Absolute Pressure Transducer, Kavlico 30 PSI 011-05783-00 1
Type K Thermocouple, 3/8-24 Threaded, CHT, Alcor 86253 494-70000-00 6
Type K Thermocouple, Clamp, EGT, Alcor 86255 494-70001-00 6
RTD, Oil Temperature, UMA 1B3-2.5R 494-70004-00 1
Shunt, Ammeter, +/-50 mV, 100 Amps, UMA 1C4 909-D0000-00 1
