Garmin G3X - 16.4 Required Equipment; 16.4.1 Additional Equipment Required

190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 16-5
16.4 Required Equipment
Table 16-5 lists the kits available for the GSA 28.
16.4.1 Additional Equipment Required
• Cables: The installer will fabricate and supply all system cables.
• Mounting hardware is included in the available mounting kits.
Table 16-5 GSA 28 Available Equipment w/Weights
Item Garmin P/N Weight
GSA 28 Connector Kit 011-02950-00 0.12 lb (0.054 kg)
GSA 28 Connector Kit, 90° 011-02950-01 0.13 lb (0.059 kg)
GSA 28 Stop Bracket Kit 011-02951-00 0.03 lb (0.014 kg)
GSA 28 Mounting Kit, Generic, Push-Pull 011-02952-00 0.26 lb (0.118 kg)
GSA 28 Mounting Kit, Generic, W/Bracket 011-02952-01 0.50 lb (0.227 kg)
GSA 28 Mounting Kit, Generic, Capstan 011-02952-02 0.14 lb (0.064 kg)
GSA 28 Mounting Kit, RV-6 Roll 011-02952-10 0.55 lb (0.250 kg)
GSA 28 Mounting Kit, RV-4/8 Pitch 011-02952-11 0.51 lb (0.231 kg)
GSA 28 Mounting Kit, RV-7/8/10 Roll 011-02952-12 0.42 lb (0.191 kg)
GSA 28 Mounting Kit, RV-9 Roll 011-02952-13 0.42 lb (0.191 kg)
GSA 28 Mounting Kit, RV-6/7/9 Pitch 011-02952-14 0.37 lb (0.168 kg)
GSA 28 Mounting Kit, RV-10 Pitch 011-02952-15 0.48 lb (0.218 kg)
GSA 28 Mounting Kit, RV-10 Yaw 011-02952-16 0.60 lb (0.272 kg)
GSA 28 Removal Adapter 011-03158-00 0.03 lb (0.014 kg)
Table 16-6 Contents of Connector Kit (011-02950-00)
Item Garmin P/N Quantity
Sub-Assy, Bkshl w/Hdw, Jackscrew, 15/26 Pin 011-01855-01 1
GSA 28 Removal Adapter 011-03158-00 1
Connector, Rcpt, D-SUB, Crimp Socket,Commercial,15 Ckt 330-00625-15 1
Cont,Sckt,Mil Crp,Size 20,20-24 AWG,RoHS 336-00022-02 16
Table 16-7 Contents of Connector Kit, 90° (011-02950-01)
Item Garmin P/N Quantity
Sub-Assy, Bkshl w/Hdw, Jackscrew, 90°,15/26 Pin 011-01959-01 1
GSA 28 Removal Adapter 011-03158-00 1
Connector, Rcpt, D-SUB, Crimp Socket,Commercial,15 Ckt 330-00625-15 1
Cont,Sckt,Mil Crp,Size 20,20-24 AWG,RoHS 336-00022-02 16
