190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual

Rev. AV Page 6-13

6.9 GDU 470 Outline and Installation Drawings

Figure 6-10 GDU 470 Outline Drawing

7.82

198.6

6.01

152.6

3.68 93.4

2.70 68.6

FRONT SURFACE OF PANEL

.41

10.3

1.68 42.6

.58

14.7

1.53 38.7

FRONT SURFACE OF PANEL

7.24

184.0

2.24 56.8

1.75 44.4

5.42

137.6

.30 7.5

.96

24.4

.83

21.0

.29 7.3

6.91

175.6

2X 2.09

53.0

4.27

108.6

NOTES:

1. DIMENSIONS: INCHES [mm]

2. DIMENSIONS ARE SHOWN FOR REFERENCE ONLY.
