21.2.3 Jabiru Engine Applications
Table 21-7 lists the sensors used in G3X installations with Jabiru engines. See Section 29
for Jabiru engine
sensor wiring information.
Table 21-7 Jabiru Sensors
Sensor Type Details/Part Number
RPM Use Jabiru tachometer output from alternator
Manifold pressure Use Garmin GPT 30A (011-05783-00)
Oil pressure Use Jabiru-supplied VDO pressure sensor, or 150 GPT
Oil temperature
Use Jabiru-supplied VDO 50-150°C thermistor, or any compatible RTD
such as UMA 1B3XR series
Exhaust gas temperature Use Jabiru-supplied Type K thermocouples
Cylinder head temperature Use Jabiru-supplied Type J thermocouples
Fuel pressure Use Garmin GPT 15G (011-05783-10)
Fuel flow Use EI FT-60 (494-10001-00) or Floscan 201B-6
