Garmin G3X - 6.7 GDU 45 X Outline and Installation Drawings

190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 6-7
6.7 GDU 45X Outline and Installation Drawings
Figure 6-4 GDU 45X Outline Drawing
(2X)
2.13
54.2
4.32
109.7
FRONT SURFACE OF PANEL
.58
14.7
10.3
.41
38.7 1.52
1.68
42.6
7.5 .30
.87
22.2
(2X)
6.96
176.8
.88
22.3
(3X)
42.3 1.66
(2X)
54.7 2.15
7.5 .30
7.40
188.0
5.33
135.5
NOTES:
DIMENSIONS: INCHES [mm]1. DIMENSIONS ARE SHOWN FOR REFERENCE ONLY.2.
FRONT SURFACE OF PANEL
2.70
68.6
3.68
93.4
7.99
203.0
5.93
150.5
