Garmin G3X - 25.3 Dual GTR 20 Interconnect Drawings

190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 25-7
25.3 Dual GTR 20 Interconnect Drawings
Figure 25-3.1 Dual GTR 20/CAN Bus Interconnect Drawing
COM ANTENNA
CAN BUS LO
CAN BUS HI
CAN TERM A
CAN TERM B
26
25
27
8
ID IN
ID LO
P2001
GARMIN
J2001
P2002
GTR 20 AS COM 1
P2001
GARMIN
J2001
COM ANTENNACOM ANTENNA
P2002
TIE TOGETHER TO IDENTIFY GTR AS COM 2.
SEE NOTE 16
27
8
ID IN
ID LO
GTR 20 AS COM 2
COM ANTENNA
CAN BUS LO
CAN BUS HI
P2001J2001
CAN TERM A
CAN TERM B
26
25
CAN NODE LENGTH 0.3 METERS MAXIMUM
J2002
J2002
S
LEAVE OPEN TO IDENTIFY GTR AS COM 1.
SEE NOTE 16
JUMPER REQUIRED WHEN LOCATED AT
END OF THE CAN BUS. SEE NOTE 10.
JUMPER REQUIRED WHEN LOCATED AT
END OF THE CAN BUS. SEE NOTE 10.
CAN NODE LENGTH 0.3 METERS MAXIMUM
S
6
7
6
7
