22.7 Circular Connector
Components for a Circular Connector with AS85049/124S Saddle Clamp Strain Relief or AS85049/126S
Right Angle Saddle Clamp Strain Relief Installation (see Figure 22-15
for Right Angle Strain Relief)
Table 22-9 Components for a Circular Connector
Figure Ref Description GPN, NAS, or military p/n
1* Circular Connector Reference Product Installation Manual
2*
Contacts (provided with circular
connector)
Reference Product Installation Manual
3*
Saddle Clamp Strain Relief (AS85049/
124S, self-locking or AS85049/126S
right angle, self-locking)
Reference Product Installation Manual
#4 Captive Self-Locking Nut and #4
Screw (connector size 17 and smaller)
#6 Captive Self-Locking Nut and #6
Screw (connector size 19 thru size 23)
#8 Captive Self-Locking Nut and #8
Screw (connector size 25)
Parts supplied with strain relief
Cable Clamps
4
Multiple Conductor Shielded Cable
(2 –conductor demonstrated here)
Reference Installation Wiring Diagrams
5
Drain Wire Shield Termination (method
optional)
Parts used depend on method chosen (see
Section 5 thru Section 11)
6
Braid, Flat (19-20 AWG equivalent,
tinned plated copper strands 36 AWG,
Circular Mil Area 1000 -1300)
Parts used depend on method chosen
7
Floating Shield Termination (method
optional)
Parts used depend on method chosen (see
Section 5 thru Section 11)
*Indicates part is included in Garmin connector kit
