190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 22-23
8
Ring terminal, #4, insulated, 18-22 AWG MS25036-148
Ring terminal, #4, insulated, 14-16 AWG
(connector size 17 and smaller)
or
Ring terminal, #6, insulated, 18-22 AWG
MS25036-152
or
MS25036-102
Ring terminal, #6, insulated, 14-16 AWG MS25036-107
Ring terminal, #6, insulated, 10-12 AWG
(connector size 19 thru size 23)
or
Ring terminal, #8, insulated, 18-22 AWG
MS25036-111
or
MS25036-149
Ring terminal, #8, insulated, 14-16 AWG MS25036-153
Ring terminal, #8, insulated, 10-12 AWG
(connector size 25)
MS25036-156
9*
Flat Washer, Stainless, #4, .032” thick,
.115”ID, .209”OD (connector size 17 and
smaller)
Flat Washer, Stainless, #6, .032” thick,
.143”ID, .267”OD (connector size 19 thru
size 23)
Flat Washer, Stainless, #8, .032” thick,
.169”ID, .304”OD (connector size 25)
NAS620C4
or
NAS620C6
or
NAS620C8
10 Silicone Fusion Tape 249-00114-00 or similar
Not
Shown*
Connector Seal Plug - sized to match the
connector contact size (install connector
seal plugs in unused pin position per
section 12)
Reference Product Installation Manual
Table 22-9 Components for a Circular Connector
*Indicates part is included in Garmin connector kit
