Garmin G3X - 23.3.3 P4503;4603;4703 (PX03) Connector

190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 23-17
23.3.3 P4503/4603/4703 (PX03) Connector
Do not use P4X03, this connector is reserved for future development.
Figure 23-9 View of P4X03 Connector from Back of Unit
Pin Pin Name I/O
1 CAN BUS HI I/O
2 CAN BUS LO I/O
3 RESERVED --
4 RESERVED --
5 RESERVED --
6 RESERVED --
7 RESERVED --
8 RESERVED --
9 RESERVED --
