190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 23-16
23 RS-232 IN 4 In
24 RS-232 IN 5 In
25 CDU SYSTEM ID PROGRAM* 3 In
26 28V LIGHTING BUS HI In
27 SIGNAL GROUND --
28 CAN BUS TERMINATION --
29 RS-232 IN 3 In
30 RS-232 OUT 2 Out
31 AIRCRAFT POWER 2 In
32 AIRCRAFT POWER 1 In
33 CONFIG MODULE CLOCK I/O
34 SIGNAL GROUND --
35 SIGNAL GROUND --
36 SIGNAL GROUND --
37 SIGNAL GROUND --
38 CDU SYSTEM ID PROGRAM* 5 In
39 CDU SYSTEM ID PROGRAM* 6 In
40 RS-232 OUT 4 Out
41 RS-232 OUT 5 Out
42 CDU SYSTEM ID PROGRAM* 4 In
43 14V LIGHTING BUS HI In
44 SIGNAL GROUND --
45 CAN BUS LO I/O
46 CAN BUS HI I/O
47 RS-232 IN 1 In
48 RS-232 OUT 1 Out
49 CONFIG MODULE GROUND --
50 CONFIG MODULE DATA I/O
Pin Pin Name I/O
*Indicates Active Low
