190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 11-7
Figure 11-6 GMC 307 Panel Cutout Template
NOTES:
1. DIMENSIONS: INCHES [mm]. METRIC VALUES ARE FOR REFERENCE ONLY.
2. TOLERANCES: INCH mm
.XX ±.02 .X ±0.5
.XXX ±.010 .XX ±0.25
50.31.98
6.015 152.78
BEZEL OUTLINE
(REF.)
IMPORTANT!
MAKE SURE THE PAGE SCALING SETTING IS SET TO NONE
WHEN PRINTING THIS PAGE. VERIFY DIMENSIONS OF
PRINTED TEMPLATE ARE ACCURATE BEFORE CUTTING
PANEL.
GMC 307 PANEL CUTOUT
CUT OUT PANEL
TO INSIDE LINE
