6. Install a ring terminal onto the cable shield drains, grouping wires as appropriate for the connector.
See following note.
7. Place the following items on the 8-32 x 0.312 pan head shield terminal screw (8) in the order they
are presented.
a) Split washer (9)
b) Flat washer (10)
c) First ring terminal (7)
d) Second ring terminal (if necessary)
8. Insert the pan head shield terminal screw (8) into a tapped hole on the shield block.
NOTE
Each tapped hole on the shield block may accommodate up to two ring terminals. It is
preferred that only two wires be terminated per ring terminal. This necessitates the use of
a #8 ring terminal, insulated, 14-16 AWG (MS25036-153). If only a single wire is left or if
only a single wire is needed for this connector, a #8 ring terminal, insulated, 18-22 AWG
(MS25036-149) can be used. If more wires exist for the connector than two per ring
terminal, it is permissible to terminate a maximum of three wires per ring terminal.
9. Secure connector to mating connector on avionics device using the knurled thumb screws. The end
of each thumb screw accepts a 3/32” hex wrench (Figure 22-9
) to aid in securing the connector.
