17 FADEC_CAN2_H I/O
18 GP 1 HI / +5V Out
19 GP 1 In
20 GP 1 LO / GND --
21 GP 2 HI / +5V Out
22 GP 2 In
23 GP 2 LO / GND --
24 GP +5V_2 Out
25 VOLTS 1 In
26 GP GND_2 --
27 GP +5V_3 Out
28 VOLTS 2 In
29 GP GND_3 --
30 GP HI / +5V Out
31 GP 5 In
32 GP 5 LO / GND --
33 FADEC_CAN2_L I/O
34 FUEL XDCR +12V_3 Out
35 FUEL XDCR +12V_4 Out
36 FUEL FLOW (shared with Pin 23, J243 connector) In
37 FUEL RETURN (shared with Pin 21, J243 connector) In
38 FUEL XDCR GND_3 --
39 FUEL XDCR GND_4 --
40 DISCRETE IN** 1 In
41 DISCRETE IN** 2 In
42 DISCRETE IN** 3 In
43 DISCRETE IN** 4 In
44 DISCRETE OUT* 1 / MASTER WARNING In
45 DISCRETE OUT* 2 / MASTER CAUTION In
46 SHUNT 2 HI (shared with Pin 35, J243 connector) In
47 SHUNT 2 LO (shared with Pin 34, J243 connector) In
48 FADEC_CAN3_HI (GEA 24B ONLY, 010-02770-00) In
49 FADEC_CAN3_LO (GEA 24B ONLY, 010-02770-00) In
50 GP +12V Out
Pin Pin Name I/O
*Indicates Active Low
**Can be configured as active high or active low
