190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 23-68
30 ARINC 429 OUT 2 A Out
31 MUTUAL SUPPRESSION I/O I/O
32 NOT USED --
33 NOT USED --
34 ARINC 429 OUT 1 B Out
35 NOT USED --
36 NOT USED --
37 ARINC 429 OUT 1 A Out
38 NOT USED --
39 POWER GROUND --
40 NOT USED --
41 NOT USED --
42 AIRCRAFT POWER 1 In
43 RS-232 GROUND --
44 NOT USED --
45 NOT USED In
46 TIS CONNECT SELECT* In
47 NOT USED --
48 NOT USED --
49 NOT USED --
50 RS-232 GROUND 2 --
51 NOT USED --
52 NOT USED --
53 NOT USED --
54 NOT USED --
55 NOT USED --
56 AIRCRAFT POWER 2 In
57 NOT USED --
58 POWER GROUND --
59 NOT USED --
60 AIRCRAFT POWER 2 In
61 NOT USED --
62 NOT USED --
Pin Pin Name I/O
*Denotes active low (ground to activate)
