Rev. AV Page 24-43
GMA 240/245
TRAFFIC SYSTEM
GTS 8XX
59
58
ALERT 2 AUDIO IN HI 44
ALERT 2 AUDIO IN LO 43
S
ALERT AUDIO OUT HI
ALERT AUDIO OUT LO
P80002
GDU 46X/37X (MFD)
RS-232 TX 3 13
SIGNAL GROUND 34
RS-232 RX 3 29
S
SIGNAL GROUND7
RS-232 IN 26
RS-232 OUT 25
S
P80001
CONFIGURATION GUIDANCE (GTS 8X0 V4.10 AND LATER, GTS 8X5 V3.10 AND LATER)
1. GTS 8XX - ALL INSTALLATIONS
A.UNDER "TRAFFIC DISPLAY DESTINATION", SET "ENHANCED COM PORT" TO RS-232 PORT 2
B. ON CONFIGURATION PAGE SET "ADS-B RECEIVER" TO "ON" AND CHECK "ALLOW ADS-B IN STANDBY”
2. GTS 8XX INSTALLED WITH GTX 35R/335/335R TRANSPONDER
A.UNDER "TRANSPONDER 1 COMMUNICATION" SET A429 PRIMARY TX/RX TO TX/RX
CHANNEL 2 AND SELECT “HIGH SPEED”
B. UNDER "GPS POSITION/VELOCITY/TIME SOURCE", SET A429 PRIMARY TO RX CHANNEL 2
AND SELECT “HIGH SPEED”
C.UNDER “BAROMETRIC ALTITUDE SOURCE”, SET A429 PRIMARY TO RX CHANNEL 2 AND
SELECT “HIGH SPEED”
D.UNDER “MAGNETIC HEADING SOURCE", SET A429 PRIMARY TO RX CHANNEL 2 AND
SELECT “HIGH SPEED”
2. GDU 46X/37X (GDU 4XX V8.50 AND LATER)
A.ON THE GDU 46X/37X RS-232 CONFIG MODE PAGE
SET CONNECTED GDU 46X/37X RS-232 CHANNEL FORMAT TO "GTS INSTRUMENT
DATA"
B. ON THE GDU 46X/37X XPDR CONFIG MODE PAGE
IF A REMOTE TRANSPONDER IS CONFIGURED WHICH SUPPORTS TIS-A TRAFFIC,
DISABLE THIS FEATURE
C.ON THE GDU 46X/37X SOUND CONFIG MODE PAGE
SET "TRAFFIC AUDIO" AND "TRAFFIC N/A ALERT" TO "OFF" IF ONE OF THE TRAFFIC
ALERT AUDIO CONNECTIONS TO THE AUDIO PANEL SHOWN ABOVE IS WIRED.
P2401
REFER TO THE GTS 8XX INSTALLATION MANUAL FOR ADDITIONAL WIRING INFORMATION
SUCH AS POWER, USB, AND TRANSPONDER CONNECTIONS AS WELL AS CONFIGURATION
GUIDANCE. DO NOT USE RS-232 PORT 1 ON THE GTS 8XX UNIT.
P4602/P3701
OPTIONAL AUDIO PANEL CONNECTION ONLY
WHEN GDU TRAFFIC ALERTS ARE DISABLED
48 EXTERNAL SUPPRESSION
P80002
P80001
GTX 35R/335/335R
26
25
ARINC 429 OUT 1A 5
ARINC 429 OUT 1B 6
S
ARINC 429 IN 2A
ARINC 429 IN 2B
P3251
S
S S
18EXTERNAL SUPPRESSION
GTS INSTRUMENT DATA
FORMAT 5
(ENHANCED COM PORT)
6
1
S
P3252
S
53
52
ETHERNET OUT B
ETHERNET OUT A
2
7
GTX 45R/345/345R ONLY
S
54 ETHERNET IN A
55 ETHERNET IN B
ETHERNET OUT 1A
ETHERNET IN 1B
ETHERNET IN 1A
ETHERNET OUT 1B
S
GTX 35R/335/335R ONLY
GTX 45R/345/345R ONLY
GTX 45R/345/345R
RS-232 TX 1 48
SIGNAL GROUND 27
RS-232 RX 1 47
S
CONNEXT 57600 BAUD
RS-232 TX 2 8
RS-232 GND 2 51
RS-232 RX 2 30
S
CONNEXT FMT 1
GTX 45R/345/345R ONLY
CORRELATED ADS-B AND ACTIVE TRAFFIC
GDU 4XX ONLY
P3251
47
46
S
GMA 240/245
ALERT 2 AUDIO IN HI 44
ALERT 2 AUDIO IN LO 43
S
P2401
AUDIO OUT LO
AUDIO OUT HI
OPTIONAL AUDIO PANEL CONNECTION ONLY
GTX 45R/345/345R ONLY
GTX 35R/335/335R ONLY
WHEN GDU TRAFFIC ALERTS ARE DISABLED
NOTE: THIS INTERFACE EXAMPLE DRAWING IS NOT SUFFICIENT FOR INSTALLATION OF A GTS 8XX
TRAFFIC SYSTEM. PLEASE REFERENCE THE APPROPRIATE INSTALLATION DOCUMENTATION FOR THE
GTS 8XX SERIES UNIT FOR COMPREHENSIVE INSTALLATION AND CONFIGURATION INFORMATION.
