Garmin G3X - Page 484

190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 28-7
Figure 28-2.5 GEA 24 - Dual UL Power FADEC Wiring Example
S
CAN BUS
CAN NODE LENGTH
0.3 METER MAXIMUM
CAN NODE
NOTES
1. WIRING GUIDANCE
A. THE END OF THE CAN BUS AT THE UL POWER ECU REQUIRES AN ITT CANNON SURE
SEAL PLUG CONNECTOR PART NUMBER
120-8552-101
2. G3X CONFIGURATION GUIDANCE
A. NO CONFIGURATION REQUIRED ON GEA 24 TO ENABLE CAN BUS
B. ON THE ENGINE CONFIGURATION PAGE
SET PROBE TYPE ON FADEC SUPPORTED ENGINE PARAMETERS
TO "UL POWER FADEC"
CAN2_HI 17
CAN2_LO
GEA 24
P244
33
CAN2_LO
33
GND
2
UL POWER ECU
CAN HI
CAN LO2
3
GND1
1
2
3
UL POWER ECU
GND
CAN LO2
1
CAN HI3
1
2
3
