Garmin G3X - Page 486

190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 28-9
Figure 28-3 GSU 73 - Rotax 912/914 Sensor Wiring Examples, Page 2 of 2
GSU 73
J732
52
72
S
CARB/COOLANT
TEMPERATURE
POS 5 / TEMP 1
POS 5 / TEMP 1
EGT 6 / MISC 1 HI
EGT 6 / MISC 1 LO
31
11
COOLANT PRESS SENSOR
S
GROUND
OUTPUT
SUPPLY VOLTAGE+5V TRANSDUCER POWER 75
56
GARMIN GPT 75G OR
KAVLICO P4055-5020-3
XDCR PWR OUT LO (GND)
B
C
A
SEE NOTE 12
ROTAX P/N 965531
