190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page iii
NOTE
References to the GDU 45X throughout this manual apply equally to the GDU 450 and
GDU 455 except where specifically noted.
NOTE
References to the GDU 46X throughout this manual apply equally to the GDU 460 and
GDU 465 except where specifically noted.
NOTE
References to the GDU 4XX throughout this manual apply equally to the GDU 45X,
GDU 46X, and GDU 47X except where specifically noted.
NOTE
References to the GEA 24 throughout this manual apply equally to the GEA 24B except
where specifically noted.
NOTE
References to the GMC Mode Controller throughout this manual apply equally to the
GMC 305, GMC 307, and GMC 507 except where specifically noted.
NOTE
References to the GSU 25 throughout this manual apply equally to the GSU 25B,
GSU 25C, and GSU 25D except where specifically noted.
NOTE
The term LRU, as used throughout this manual is an abbreviation for Line Replaceable
Unit. LRU is used generically in aviation for a product (such as a GDU 37X or GTP 59)
that can be readily “swapped out” (usually as a single component) for troubleshooting/
repair.
NOTE
All GMU 22 information in this Installation Manual also applies to the GMU 44. The
GMU 44 had previously been used as the G3X magnetometer but has been replaced by the
GMU 22.
NOTE
Connector references JXXX(X) and PXXX(X) are used throughout this document. The
letter “J” or “P” designates the connector (whether on the LRU or wiring harness). “J”
(Jack) refers to the connector on the LRU, and “P” (Plug) refers to the connector on the
wiring harness. “J” or “P” designate the connector only, regardless of contact type (pin
or socket). However GDU 4XX connectors on the LRU are designated as P4X0X.
NOTE
The GDU 37X/4XX products contain a lithium battery that must be recycled or disposed
by professional services according to applicable governing laws. Only Garmin-authorized
service facilities are permitted to perform maintenance on this product.
