190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 30-116
S-TEC
System 20
Analog,
Discrete
Analog Autopilot Configuration Page:
Autopilot Type: “S-Tec System 20”
GPS Steering: “Enabled”
GPSS Scale Factor: “1.000”
Must be configured to operate
with KI-525 (KCS-55) heading
system.
System 30
Analog,
Discrete
Analog Autopilot Configuration Page:
Autopilot Type: “S-Tec System 30”
GPS Steering: “Enabled”
GPSS Scale Factor: “1.000”
Must be configured to operate
with KI-525 (KCS-55) heading
system.
System 40
Analog,
Discrete
Analog Autopilot Configuration Page:
Autopilot Type: “S-Tec System 40”
GPS Steering: “Enabled”
GPSS Scale Factor: “1.000”
Must be configured to operate
with KI-525 (KCS-55) heading
system.
System 50
Analog,
Discrete
Analog Autopilot Configuration Page:
Autopilot Type: “S-Tec System 50”
GPS Steering: “Enabled”
GPSS Scale Factor: “1.000”
Must be configured to operate
with KI-525 (KCS-55) heading
system.
System 55
Analog,
Discrete
Analog Autopilot Configuration Page:
Autopilot Type: “S-Tec System 55”
GPS Steering: “Enabled”
GPSS Scale Factor: “1.000”
Must be configured to operate
with KI-525 (KCS-55) heading
system.
System
55X
Analog,
Discrete,
ARINC 429
Analog Autopilot Configuration Page:
Autopilot Type: “S-Tec System 55X”
Must be configured to operate
with KI-525 (KCS-55) heading
system.
System 60
Analog,
Discrete
Analog Autopilot Configuration Page:
Autopilot Type: “S-Tec System 60”
GPS Steering: “Enabled”
GPSS Scale Factor: “1.000”
Must be configured to operate
with KI-525 (KCS-55) heading
system.
System 65
Analog,
Discrete
Analog Autopilot Configuration Page:
Autopilot Type: “S-Tec System 65”
GPS Steering: “Enabled”
GPSS Scale Factor: “1.000”
Must be configured to operate
with KI-525 (KCS-55) heading
system.
Piper
Autocontrol
III/IIIB
Analog
Analog Autopilot Configuration Page:
Autopilot Type: “Piper AutoControl”
GPS Steering: “Enabled”
GPSS Scale Factor: “1.000”
Altimatic III/
IIIB-1/IIIC
Analog
Analog Autopilot Configuration Page:
Autopilot Type: “Piper Altimatic”
GPS Steering: “Enabled”
GPSS Scale Factor: “1.000”
Table 30-13 Compatible Equipment – Autopilots
MFR Model
Data
Format
G3X Configuration Setting
Interfacing Equipment
Configuration Information
