Pitch Trim Speed
The GSA 28 pitch servo will control the elevator trim on the aircraft.
The Pitch Trim Motor Speed percentage for the Fastest Movement is the
speed in which the pitch servo will run the auxiliary trim motor when at or
below the corresponding airspeed.
The Pitch Trim Motor Speed percentage for the Slowest Movement is the
speed in which the pitch servo will run the auxiliary trim motor when at or
above the corresponding airspeed.
Yaw Trim Speed
The GSA 28 yaw servo will control the rudder trim on the aircraft.
The Yaw Trim Motor Speed percentage for the Fastest Movement is the
speed in which the roll servo will run the auxiliary trim motor when at or
below the corresponding airspeed.
The Yaw Trim Motor Speed percentage for the Slowest Movement is the
speed in which the roll servo will run the auxiliary trim motor when at or
above the corresponding airspeed.
Trim Airspeed Source Airspeed trim scheduling can be set to reference or indicated airspeed.
Table 30-17 Trim Speed Tab, Trim Configuration Settings
Configuration Setting Description
