The transmitted labels are as follows:
100P Selected Course 1 203 Pressure Altitude 204 Baro Corrected Altitude
205 Mach Number 206 Indicated Airspeed 210 True Airspeed
211 Total Air Temperature 212 Vertical Speed 213 Static Air Temperature
235 Baro Setting (BCD) 244 Fuel Flow 244P Fuel Mass Flow
247 Total Fuel Quantity 247P Fuel Mass 320 Magnetic Heading
332 Lateral Acceleration 371G Manufacturer ID 377 Equipment ID
Autopilot–For use with Autopilots that use both RS-232 and ARINC 429 data. The transmitted labels are
as follows:
001 Distance To Waypoint (BCD) 012 Ground Speed (BCD) 100P Selected Course 1
101 Selected Heading 102 Selected Altitude 104 Selected Vertical Speed
114 Desired Track (True) 115 Waypoint Bearing (True) 116G Cross Track Distance
117G Vertical Deviation 121 Roll Command 122 Pitch Command
147G Magnetic Variation 203 Pressure Altitude 204 Baro Corrected Altitude
206 Indicated Airspeed 212 Vertical Speed 235 Baro Setting (BCD)
251 Distance To Waypoint 312 Ground Speed 313 Ground Track
320 Magnetic Heading 324 Pitch Angle 325 Roll Angle
371G Manufacturer ID 377 Equipment ID
ARINC 429 Inputs:
Garmin GPS–Receives GPS labels from a panel-mount GPS navigator (GTN/GNS). A second selection is
used to find if the GPS input is from NAV 1 or NAV 2.
Garmin VOR/ILS–Receives VOR/ILS labels from a panel-mount GPS navigator (GTN/GNS) with
VOR/ILS NAV receiver. A second selection is used to find if the GPS input is from NAV 1 or
NAV 2.
Radar Altimeter - Receives Radar Altimeter ARINC 429 labels 164 and 165.
NOTE
Some panel-mount GPS navigators and NAV/COM radios do not transmit ARINC 429
data when they are in configuration mode. To verify ARINC 429 connections, make sure
these units are operating in normal mode.
