190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 30-168
Radio 3D Audio
3D Audio is useful when multiple audio sources are present. 3D audio
processing creates the illusion that each audio source is coming from a
unique location or seat position by using different responses in each
ear. Because this feature uses different signals for left and right
channels, it requires wiring for stereo intercom and stereo headsets. If
3D audio is activated when mono headsets are in use, the listener will
still hear all audio sources; however, there is no benefit from location
separation.
When set to Enabled with a single COM selected, the listener hears
the audio source at the 12 o’clock position. If both COMs are selected,
the listener hears COM 1 at 11 o’clock and COM 2 at the 1 o’clock
position.
Intercom 3D Audio
Select Enabled to allow the listener to hear others in the intercom
positioned relative to their seating location.
Speaker
Turns the speaker on/off when the speaker is enabled using the
“Enabled/Disabled” selection.
Volume
Sets the volume for the speaker when the speaker is enabled using the
“Enabled/Disabled” selection.
Enabled/Disabled (GMA 245R only)
Enable (show) or disable (hide) the audio panel page speaker control.
Music 1 Title
Music 2 Title (GMA 245 only)
Music 1
Music 2 (GMA 245R only)
Title
Used to set the titles of the music source selections on the audio panel
page when the music source is enabled using the “Enabled/Disabled”
selection.
Enabled/Disabled (GMA 245R only)
Enable (show) or disable (hide) the audio panel page music controls.
Table 30-18 Audio Panel Configuration Settings
Selection Description
