190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 30-227
Engine power is displayed (in percentage) between the RPM and manifold pressure gauges in the EIS
display and on the Engine page.
Figure 30-75 Engine Power Display
With a Rotax 912iS/915iS/916iS FADEC engine, if Engine Power is configured for “FADEC” and the
aircraft is on the ground with the engine stopped, the EIS display and Engine page will display the FADEC
throttle position to assist in engine starting. This is shown as a percentage of maximum throttle position,
preceded by a ‘T’.
Figure 30-76 Rotax FADEC Throttle Position Display
