190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page C-13
Audio Panel failure 110 1
‘0’ = no status
failure
‘1’ = status failure
Transponder mode 111 1
‘N’ = On
‘A’ = Alt
‘S’ = Standby
‘G’ = Gnd
Transponder code 112 4 0000 9999
Transponder ident flag 116 1 1 = set, 0 = clear 0 1
Transponder reply flag 117 1 1 = set, 0 = clear 0 1
Transponder flight ID 118 8
Transponder failure 126 1
‘0’ = no status
failure
‘1’ = status failure
0 1
Checksum 127 2 ASCII hex
sum of all previous
bytes
CR/LF 129 2 0x0D / 0x0A
Total length 131
Table C-10 CNI Message Format
Field Name Offset Width Units Notes Min Max
