190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page F-6
33 ARINC 429 IN 4 B In
34 SIGNAL GROUND --
35 SIGNAL GROUND --
36 SIGNAL GROUND --
37 SIGNAL GROUND --
38 MAGNETOMETER POWER OUT Out
39 MAGNETOMETER GROUND --
40 SIGNAL GROUND --
41 SPARE --
42 SPARE --
43 SIGNAL GROUND --
44 SPARE --
45 SPARE --
46 SPARE --
47 AIRCRAFT POWER 1 In
48 SPARE --
49 AIRCRAFT POWER 2 In
50 SPARE --
51 SPARE --
52 SPARE --
53 SIGNAL GROUND --
54 SIGNAL GROUND --
55 SPARE --
56 SPARE --
57 SPARE --
58 SIGNAL GROUND --
59 POWER GROUND --
60 SIGNAL GROUND --
61 POWER GROUND --
62 SPARE --
Pin Pin Name I/O
*Indicates Active Low
