190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page F-8
30 EGT 5 HI In
31 EGT 6 / MISC PRESS HI In
32 VOLTS 2 HI In
33 CHT 6 HI In
34 OIL TEMP HI In
35 OAT PROBE IN LO In
36 CAP FUEL 1 / RPM 2 In
37 SIGNAL GROUND --
38 CAP FUEL 2 / FUEL FLOW 2 In
39 CONFIG MODULE DATA I/O
40 CHT 4 LO In
41 CHT 1 LO In
42 EGT 4 LO In
43 EGT 1 LO In
44 FUEL 2 LO In
45 FUEL PRESS LO In
46 POS 4 / GP 4 / FUEL 4 LO In
47 POS 1 / GP 1 / TIT 1 HI In
48 SHUNT 2 HI In
49 OIL PRESS LO In
50 SHUNT 1 LO In
51 VOLTS 1 LO In
52 POS 5 / MISC TEMP LO In
53 CHT 5 LO In
54 SPARE --
55 +12 VDC TRANSDUCER POWER OUT Out
56 TRANSDUCER POWER OUT LO (GROUND) --
57 TRANSDUCER POWER OUT LO (GROUND) --
58 +10 VDC TRANSDUCER POWER OUT Out
59 CONFIG MODULE POWER OUT Out
60 CHT 4 HI In
61 CHT 1 HI In
62 EGT 4 HI In
63 EGT 1 HI In
64 FUEL 2 HI In
65 MAN PRESS HI In
66 POS 4 / GP 4 / FUEL 4 HI In
67 POS 1 / GP 1 / TIT 1 LO In
68 SHUNT 2 LO In
Pin Pin Name I/O
*Indicates Active Low
