190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page F-15
Pin Connector Pin Name I/O
64 J732 FUEL 2 HI IN
44 J732 FUEL 2 LO IN
26 J732 FUEL PRESS HI IN
45 J732 FUEL PRESS LO IN
65 J732 MAN PRESS HI IN
6 J732 MAN PRESS LO IN
71 J732 VOLTS 1 HI IN
51 J732 VOLTS 1 LO IN
32 J732 VOLTS 2 HI IN
12 J732 VOLTS 2 LO IN
31 J732 EGT 6 / MISC PRESS HI IN
11 J732 EGT 6 / MISC PRESS LO IN
69 J732 OIL PRESS HI IN
49 J732 OIL PRESS LO IN
47 J732 POS 1 / GP 1 / TIT 1 HI IN
67 J732 POS 1 / GP 1 / TIT 1 LO IN
28 J732 POS 2 / GP 2 / TIT 2 HI IN
8 J732 POS 2 / GP 2 / TIT 2 LO IN
27 J732 POS 3 / GP 3 / FUEL 3 HI IN
7 J732 POS 3 / GP 3 / FUEL 3 LO IN
66 J732 POS 4 / GP 4 / FUEL 4 HI IN
46 J732 POS 4 / GP 4 / FUEL 4 LO IN
70 J732 SHUNT 1 HI IN
50 J732 SHUNT 1 LO IN
48 J732 SHUNT 2 HI IN
68 J732 SHUNT 2 LO IN
10 J732 THERMOCOUPLE REF IN HI IN
9 J732 THERMOCOUPLE REF IN LO IN
