190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page H-32
Table H-7 Magnetometer Interference Test Sequence Example
Elapsed Time Since Start of Test (min:secs) Action
0:00 Test begins
0:10 Aileron full right
0:20 Aileron full left
0:30 Aileron level
0:40 Elevator up
0:50 Elevator down
1:00 Elevator level
1:20 Rudder left
1:40 Rudder right
1:50 Rudder center
2:00 Flaps down
2:10 Flaps up
2:20 Autopilot on
2:30 Autopilot off
2:40 Landing gear up
2:50 Landing gear down
3:00 Speed brake up
3:10 Speed brake down
3:20 Navigation lights on
3:30 Navigation lights off
3:40 Landing lights on
3:50 Landing lights off
4:00 Taxi lights on
4:10 Taxi lights off
4:20 Landing + Taxi lights on
4:30 Landing + Taxi lights off
4:40 Strobes on
4:50 Strobes off
5:00 Recognition lights on
5:10 Recognition lights off
5:20
Turn on all wing-tip lights simultaneously (typically will
include navigation lights, recognition lights and strobe)
5:30 Turn off all wing-tip lights simultaneously
5:40 Beacon on
5:50 Beacon off
6:00 Pitot heat on
6:10 Pitot heat off
6:20 End of test
