Figure 6-6 GDU 45X Panel Cutout Drawing (not to scale)
0
0.0
0
0.0
3.73
94.8
2X 3.77
95.7
3.73
94.8
2X 3.77
95.7
2.70
68.5
2X 2.73
69.4
2.70
68.5
2X 2.73
69.4
C
L
C
L
7.46
189.5
5.39
137.0
4X R.29
7.4
4X
.29
7.4
4X
.29
7.4
