GE Senographe DS User Manual

Chapter 9 Page no. 1012
JC-TSG-A-001.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card TSG A001 - AWS Troubleshooting - No Display on Power Up
1-3 Monitor Adjustments and Power Checks
From page 1010
AWS apparently powering up correctly,
but no display or poor display on monitor.
No
Yes
No
Refer to monitor
video signal checks
on page 1013
If the problem persists, start again
on page 1010, or ask for help from
your OLC.
Is there a visible
display on the
monitor?
Is the monitor
operation LED lit?
No
Check the monitor power
cable. Is it wrongly
connected or defective?
Yes
Check the monitor
fuse. Is it defective?
Yes
No
Reconnect or change the
monitor power cable.
Change the monitor fuse.
Yes
Refer to LCD GS AWS Monitor
Service Manual for actions to
correct the display.
Yes
No
Connect the trackball/mouse to
the correct USB port (see
diagram on page 82). Replace
USB extender if necessary.
Check the AWS trackball
or mouse connection.
Is there a problem?
