Chapter 9 Page no. 1126
JC-DR-A-189.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A189 - Interface Board
3. Remove the three screws (1) securing the Interface board (cross-head screwdriver).
4. Remove the four threaded nuts (2) securing the Interface board, and remove the Interface board.
5. Put the defective Interface board in an anti-static bag.
1
2
To Next Page
