GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card D/R A210 - Gantry cover replacement guide
Page no. 1207 Chapter 9
JC-DR-A-210.fm
3-6-1 Head Covers - non-available covers
• If the reference of the defective part appears in the following table, it cannot be replaced individually.
A complete set of covers must be ordered and installed:
- Order a set of covers as listed below:
• Refer to section 3-8 page 1210 to install the Arm Cover Rework Assembly.
• After installation of the Arm Cover Rework Assembly, install the new covers using the information
given in Job Card PHY A044 - Remove/Reinstall Gantry Covers, section 9 page 529. Note that for
the installation of arm covers, you need to consider the case “flexible covers”.
3-6-2 Head Covers - available covers
• If the reference of the defective part appears in the following table, it can be replaced individually.
The table indicates the necessary parts to be ordered
• Install the new cover(s) using the information given in Job Card PHY A044 - Remove/Reinstall Gan-
try Covers, section 9 page 529.
Reference of defective part Description
2375043 2375043-3 Head Cover Left
2375044 2375044-3 Head Cover Right
Reference Description Quantity
2375037-4 Arm Cover Left 1
2375038-4 Arm Cover Right 1
2412297 Arm Cover Rework Assy 1
2401145-2 Compression Cover Upper 1
2401147 Compression Cover Lower 1
2375043-2 Head Cover Left 1
2375044-2 Head Cover Right 1
2399858-2 GE Logo D60 1
5130589 Kit of screws and caps for covers 1
2352894-2 Handle assembly 1
If the defective part is:
Order the following parts:
Reference Description Quantity
2375043-2 Head Cover Left 2375043-2 Head Cover Left 1
2375044-2 Head Cover Right 2375044-2 Head Cover Right 1
Order also: 5130589 Kit of screws and caps for covers 1
